Adopted unique formula material with high strength, good arc resistance, strong insulation, high temperature resistance, and good flame retardancy.
Fixed type MCCB using high-quality bimetallic elements with no capacity (current) reduction required from -5℃ to 55℃.
Features longer temperature resistance and fatigue resistance, lasting 50% longer than ordinary springs.
| Model | ARXM3-800 | ||||||||||||
| Rated current In (A) | 630A/700A/800A | ||||||||||||
| Rated current of frame size Inm (A) | 800A | ||||||||||||
| Usage category | Category A | ||||||||||||
| Rated ultimate short-circuit breaking capacity level | L | M | H | ||||||||||
| Number of poles (P) | 3P | 3P | 4P | 3P | 4P | ||||||||
| Rated working voltage Ue (V) | 400V | ||||||||||||
| Rated ultimate short-circuit breaking capacity Icu (kA) | 50kA | 75kA | 100kA | ||||||||||
| Rated service short-circuit breaking capacity Ics (kA) | 50kA | 75kA | 75kA | ||||||||||
| Rated working voltage Ue (V) | / | 690V | |||||||||||
| Rated ultimate short-circuit breaking capacity Icu (kA) | / | 30kA | / | ||||||||||
| Rated service short-circuit breaking capacity Ics (kA) | / | 20kA | / | ||||||||||
| Rated insulation voltage Ui (V) | 1000V | ||||||||||||
| Rated impulse withstand voltage Uimp (V) | 12kV | ||||||||||||
| Mechanical life (time) | 4000 | ||||||||||||
| Electrical life (time) | 1000 | ||||||||||||
| Arcing distance (mm) | ≤100 | ||||||||||||
W*L*H (mm)
|
3P | 210.5*281*116 | |||||||||||
| 4P | 281*281*116 | ||||||||||||
| package 3p | 260*305*180 | ||||||||||||
| package 4p | 325*305*180 | ||||||||||||
| weight 3P | 7728g | ||||||||||||
| weight 4P | 11200g | ||||||||||||
Risus commodo viverra maecenas accumsan lacus vel facilisis.
Risus commodo viverra maecenas accumsan lacus vel facilisis.
Risus commodo viverra maecenas accumsan lacus vel facilisis.
Risus commodo viverra maecenas accumsan lacus vel facilisis.
Risus commodo viverra maecenas accumsan lacus vel facilisis.
Risus commodo viverra maecenas accumsan lacus vel facilisis.
Risus commodo viverra maecenas accumsan lacus vel facilisis.
Risus commodo viverra maecenas accumsan lacus vel facilisis.
The ARXM3 series circuit breaker utilizes thermosetting insulating materials formulated with a unique recipe that delivers high strength, exceptional arc resistance, robust insulation, high-temperature tolerance, and outstanding flame retardancy.
No. Thanks to the highly sensitive fixed temperature sensor made from premium bimetallic materials, there is no need to reduce the operating capacity (current) within a temperature range of -5℃ to 55℃.
The spring materials used in the ARXM3 series are engineered for advanced temperature and fatigue resistance, providing a service lifespan that is 50% longer than standard electrical switch springs.
The ARXM3 series circuit breaker is designed to support front panel wiring, rear panel wiring, and plug-in rear panel wiring configurations to accommodate different installation demands.
For the 400V rated working voltage (Ue), the rated service short-circuit breaking capacity (Ics) reaches 50kA (level L), 75kA (level M), and 75kA (level H), respectively, according to the configuration.
