ARW1 series intelligent universal circuit breakers (hereinafter referred to as circuit breakers) are used in distribution networks with AC 50Hz, rated voltage up to 660V (690V) and below, rated current 200A-6300A, to distribute power and protect lines and power supply equipment from overload, undervoltage, short circuit, single-phase grounding and other faults.
The circuit breaker has intelligent protection function and precise selective protection, which can improve the reliability of power supply and avoid unnecessary power outage. At the same time, it has open communication interface and can carry out "four remote" to meet the requirements of control center and automation system.
| Model | ARW1-1600 | ||
|---|---|---|---|
| Rated current In (A) 40℃ | 200A, 400A, 630A, 800A, 1000A, 1250A, 1600A | ||
| Rated current of frame size Inm (A) | 1600A | ||
| Usage category | Category B | ||
| Number of poles (P) | 3P | 4P | |
| Rated working voltage Ue (V) | AC400V | ||
| Rated ultimate short-circuit breaking capacity Icu (kA) | 65KA | ||
| Rated service short-circuit breaking capacity Ics (kA) | 55KA | ||
| Rated short-time withstand current Icw (kA/s) | 55KA/s | ||
| Rated working voltage Ue (V) | AC690V | ||
| Rated ultimate short-circuit breaking capacity Icu (kA) | 42KA | ||
| Rated service short-circuit breaking capacity Ics (kA) | 35KA | ||
| Rated short-time withstand current Icw (kA/s) | 35KA/s | ||
| Rated insulation voltage Ui (V) | 1000V | ||
| Rated impulse withstand voltage Uimp (V) | 12kv | ||
| Arcing distance (mm) | 0 | ||
| Installation method | Draw-out type, fixed type | ||
| Electromagnetic compatibility (EMC) | Environment A | ||
| Isolation applicability | Isolation | ||
|
W*L*H (mm)
|
3P | 275×345×310 | 262×310×199 |
| 4P | 345×345×310 | 332×310×199 | |
| package 3p | 526×460×370 | ||
| package 4p | / | ||
| Weight 3p | 3800G | 2200G | |
| Weight 4p | 5500G | 2650G | |
